DS109 – Paris Metro Tunneling Project

Material:

Tunnel muck

Bulk density:

1.6 t/cu-m |

100 PCF

Material size:

150 mm |

5.9 in

Conveying rate:

800 t/h |

882 STPH

Conveying angle:

90 deg

Belt width:

1400 mm |

55 in

Belt speed:

3 m/s |

591 FPM

Lift:

26323 mm |

86.4 ft

Length:

35197 mm |

115.5 ft

Bottom drive power:

75 kW |

101 HP

Top drive power:

75 kW |

101 HP

DS091 – Continental Canada for Snap Lake Diamond Mine Project 1

Material:

Kimberlite

Bulk density:

1.6 t/cu-m |

100 PCF

Material size:

32 mm |

1.3 in

Conveying rate:

550 t/h |

606 STPH

Conveying angle:

50 deg

Belt width:

914 mm |

36 in

Belt speed:

2.2 m/s |

433 FPM

Lift:

18310 mm |

60.1 ft

Length:

39015 mm |

128 ft

Bottom drive power:

44.8 kW |

60 HP

Top drive power:

44.8 kW |

60 HP

DS090 – Continental Canada for DOFASCO Steel Project Coke Breeze

Material:

Coke breeze

Bulk density:

0.5 t/cu-m |

30 PCF

Material size:

25 mm |

1 in

Conveying rate:

32 t/h |

35 STPH

Conveying angle:

75 deg

Belt width:

762 mm |

30 in

Belt speed:

1.41 m/s |

278 FPM

Lift:

16382 mm |

53.7 ft

Length:

24835 mm |

81.5 ft

Bottom drive power:

7.5 kW |

10 HP

Top drive power:

7.5 kW |

10 HP

DS112 – Ash Grove Cement

Material:

Tire chips

Bulk density:

0.4 t/cu-m |

25 PCF

Material size:

51 mm |

2 in

Conveying rate:

9 t/h |

10 STPH

Conveying angle:

90 deg

Belt width:

762 mm |

30 in

Belt speed:

0.5 m/s |

100 FPM

Lift:

40538 mm |

133 ft

Length:

67056 mm |

220 ft

Bottom drive power:

5.6 kW |

7.5 HP

Top drive power:

5.6 kW |

7.5 HP

DS116 – Singapore Airport Tunneling Project

Material:

Tunnel muck

Bulk density:

1.8 t/cu-m |

114 PCF

Material size:

150 mm |

6 in

Conveying rate:

800 t/h |

882 STPH

Conveying angle:

45 deg

Belt width:

1200 mm |

47 in

Belt speed:

2 m/s |

394 FPM

Lift:

32783 mm |

108 ft

Length:

90142 mm |

296 ft

Bottom drive power:

75 kW |

100 HP

Top drive power:

75 kW |

100 HP

DS118 – AA Quarry vertical unit

Material:

Limestone

Bulk density:

1.6 t/cu-m |

100 PCF

Material size:

152 mm |

6 in

Conveying rate:

544 t/h |

600 STPH

Conveying angle:

90 deg

Belt width:

1372 mm |

54 in

Belt speed:

2.72 m/s |

535 FPM

Lift:

246560 mm |

808.9 ft

Length:

279900 mm |

918.4 ft

Bottom drive power:

298 kW |

400 HP

Top drive power:

298 kW |

400 HP

DS117 – LMO Cooper Consolidated

Material:

Grain

Bulk density:

0.77 t/cu-m |

48 PCF

Material size:

101.6 mm |

4 in

Conveying rate:

2268 t/h |

2500 STPH

Conveying angle:

50 deg

Belt width:

2133 mm |

84 in

Belt speed:

4.57 m/s |

900 FPM

Lift:

18474 mm |

60.6 ft

Length:

36538 mm |

119.9 ft

Bottom drive power:

112 kW |

150 HP

Top drive power:

149 kW |

200 HP
