DS116 – Singapore Airport Tunneling Project

Material:

Tunnel muck

Bulk density:

1.8 t/cu-m |

114 PCF

Material size:

150 mm |

6 in

Conveying rate:

800 t/h |

882 STPH

Conveying angle:

45 deg

Belt width:

1200 mm |

47 in

Belt speed:

2 m/s |

394 FPM

Lift:

32783 mm |

108 ft

Length:

90142 mm |

296 ft

Bottom drive power:

75 kW |

100 HP

Top drive power:

75 kW |

100 HP

DS087 – PHB Weserhutte S.A. Project

Material:

Coal

Bulk density:

0.8 t/cu-m |

50 PCF

Material size:

50 mm |

2 in

Conveying rate:

250 t/h |

276 STPH

Conveying angle:

75 deg

Belt width:

1200 mm |

47 in

Belt speed:

2.29 m/s |

450 FPM

Lift:

35100 mm |

115 ft

Length:

45065 mm |

148 ft

Bottom drive power:

30 kW |

40.2 HP

Top drive power:

30 kW |

40.2 HP

DS086 – Empire Iron Ore Mining Partnership Project

Material:

Iron ore

Bulk density:

2.4 t/cu-m |

150 PCF

Material size:

2 mm |

0.08 in

Conveying rate:

793 t/h |

708 STPH

Conveying angle:

65 deg

Belt width:

1067 mm |

42 in

Belt speed:

2.29 m/s |

450 FPM

Lift:

11522 mm |

37.8 ft

Length:

21489 mm |

70.5 ft

Bottom drive power:

29.8 kW |

40 HP

Top drive power:

37.3 kW |

50 HP

DS106 – Brucejack Mine Project

Material:

Pebble ore

Bulk density:

1.7 t/cu-m |

103 PCF

Material size:

76 mm |

3 in

Conveying rate:

45 t/h |

50 STPH

Conveying angle:

70 deg

Belt width:

914 mm |

36 in

Belt speed:

0.71 m/s |

140 FPM

Lift:

13490 mm |

44.2 ft

Length:

30900 mm |

101.5 ft

Bottom drive power:

7.5 kW |

10 HP

Top drive power:

7.5 kW |

10 HP

DS109 – Paris Metro Tunneling Project

Material:

Tunnel muck

Bulk density:

1.6 t/cu-m |

100 PCF

Material size:

150 mm |

5.9 in

Conveying rate:

800 t/h |

882 STPH

Conveying angle:

90 deg

Belt width:

1400 mm |

55 in

Belt speed:

3 m/s |

591 FPM

Lift:

26323 mm |

86.4 ft

Length:

35197 mm |

115.5 ft

Bottom drive power:

75 kW |

101 HP

Top drive power:

75 kW |

101 HP

DS108 – Paris Metro Tunneling Project

Material:

Tunnel muck

Bulk density:

1.6 t/cu-m |

100 PCF

Material size:

150 mm |

5.9 in

Conveying rate:

800 t/h |

882 STPH

Conveying angle:

90 deg

Belt width:

1400 mm |

55 in

Belt speed:

3 m/s |

591 FPM

Lift:

24647 mm |

80.9 ft

Length:

33521 mm |

110 ft

Bottom drive power:

75 kW |

101 HP

Top drive power:

75 kW |

101 HP

DS119 – EleVeyor EL, Blue Plains for WWTP Project 1

Material:

Municipal sludge

Bulk density:

1 t/cu-m |

65 PCF

Material size:

Conveying rate:

14 t/h |

15 STPH

Conveying angle:

90 deg

Belt width:

610 mm |

24 in

Belt speed:

0.38 m/s |

75 FPM

Lift:

5000 mm |

16.3 ft

Length:

11250 mm |

36.9 ft

Bottom drive power:

1.9 kW |

2.5 HP

Top drive power:

1.9 kW |

2.5 HP
