DS094 – Becma Corporation for Victor Diamond Mine Project Unit 10

Material:

Kimberlite

Bulk density:

1.6 t/cu-m |

100 PCF

Material size:

28 mm |

1.1 in

Conveying rate:

381 t/h |

420 STPH

Conveying angle:

50 deg

Belt width:

1067 mm |

42 in

Belt speed:

2 m/s |

394 FPM

Lift:

18508 mm |

60.7 ft

Length:

67581 mm |

221.7 ft

Bottom drive power:

29.8 kW |

40 HP

Top drive power:

29.8 kW |

40 HP

DS095 – Becma Corporation for Victor Diamond Mine Project Unit 11

Material:

Kimberlite

Bulk density:

1.6 t/cu-m |

100 PCF

Material size:

6 mm |

0.25 in

Conveying rate:

185 t/h |

204 STPH

Conveying angle:

50 deg

Belt width:

1067 mm |

42 in

Belt speed:

1 m/s |

197 FPM

Lift:

18508 mm |

60.7 ft

Length:

65981 mm |

216.5 ft

Bottom drive power:

18.6 kW |

25 HP

Top drive power:

18.6 kW |

25 HP

DS091 – Continental Canada for Snap Lake Diamond Mine Project 1

Material:

Kimberlite

Bulk density:

1.6 t/cu-m |

100 PCF

Material size:

32 mm |

1.3 in

Conveying rate:

550 t/h |

606 STPH

Conveying angle:

50 deg

Belt width:

914 mm |

36 in

Belt speed:

2.2 m/s |

433 FPM

Lift:

18310 mm |

60.1 ft

Length:

39015 mm |

128 ft

Bottom drive power:

44.8 kW |

60 HP

Top drive power:

44.8 kW |

60 HP

DS086 – Empire Iron Ore Mining Partnership Project

Material:

Iron ore

Bulk density:

2.4 t/cu-m |

150 PCF

Material size:

2 mm |

0.08 in

Conveying rate:

793 t/h |

708 STPH

Conveying angle:

65 deg

Belt width:

1067 mm |

42 in

Belt speed:

2.29 m/s |

450 FPM

Lift:

11522 mm |

37.8 ft

Length:

21489 mm |

70.5 ft

Bottom drive power:

29.8 kW |

40 HP

Top drive power:

37.3 kW |

50 HP

DSCo009 – DSI Horizontally Curving Downhill Regenerative Overland Conveyor TB-28 for Los Filos, Goldcorp – 300m radius

Material:

Gold Ore

Bulk density:

1.44 t/cu-m |

90 PCF

Material size:

50.8 mm |

2 in

Conveying rate:

1043 t/h |

1150 STPH

Conveying angle:

‘-5.8 deg

Belt width:

914 mm |

36 in

Belt speed:

2.3 m/s |

445 FPM

Lift:

‘-24600 mm |

‘-81.5 ft

Length:

243000 mm |

802.8 ft

Bottom drive power:

‘-74.6 kW |

‘-100 HP

Top drive power:

N/A kW |

N/A HP

DSCo012 – DSI Downhill Regenerative Overland Conveyor TB-32 for Los Filos, Goldcorp

Material:

Gold Ore

Bulk density:

1.44 t/cu-m |

90 PCF

Material size:

50.8 mm |

2 in

Conveying rate:

1043 t/h |

1150 STPH

Conveying angle:

Belt width:

914 mm |

36 in

Belt speed:

2.3 m/s |

445 FPM

Lift:

‘-9800 mm |

‘-32.3 ft

Length:

84500 mm |

277.2 ft

Bottom drive power:

‘-44.7 kW |

‘-60 HP

Top drive power:

N/A kW |

N/A HP

DS110 – M3 for Buritica Project

Material:

Pebble ore

Bulk density:

1.6 t/cu-m |

100 PCF

Material size:

76 mm |

3 in

Conveying rate:

135 t/h |

149 STPH

Conveying angle:

45 deg

Belt width:

762 mm |

30 in

Belt speed:

1.07 m/s |

211 FPM

Lift:

14250 mm |

46.8 ft

Length:

34100 mm |

111.9 ft

Bottom drive power:

11 kW |

15 HP

Top drive power:

11 kW |

15 HP
