DS107 – DSI Adder Snake at Fertilizer Project

Material:

Fertilizer prills

Bulk density:

0.8 t/cu-m |

47 PCF

Material size:

4 mm |

0.14 in

Conveying rate:

600 t/h |

661 STPH

Conveying angle:

40 deg

Belt width:

1600 mm |

63 in

Belt speed:

2 m/s |

394 FPM

Lift:

10476 mm |

34 ft

Length:

32713 mm |

107 ft

Bottom drive power:

37 kW |

50 HP

Top drive power:

37 kW |

50 HP
